12 port 6U rack
AN-CH02 can support 12 function card, 1 network management card, and 2 power supply card and can be used as centrally located SNMP managed chassis for fiber optical muxes and E1 to Ethernet inverse multiplexers.
- Support’s all type interface convertor cards, fiber modems, and (!) support mixed insert of those different boards,and functions will not be affected by each other
- You can insert 12 function boards and 2 power supply cards, and one SNMP card
- Power supply option: AC220V, DC-48V
- The positive and negative terminals can be easily exchanged for DC-48V
- Easy for installation and maintenance
- Supports power supply backup feature
- Uses standard 19 inch rack, 6U
- Convenienent for maintenance , all the LEDs in adaptor board is located on the front panel
- Sequence number of rack is displayed bynixie tube – convenient for management of large number racks used together
- Support network management
- Difference with AN-CH01 – support AN-4E1-ETH & AN-8E1-ETH interface cards
- Free SNMP software with each chassis
Application:
| AN-CH02 | 12 interface 6U Rack : 14 slot, for fiber mux (all kinds), AN-4E1-ETH; |
Description
AN-CH02 can support 12 function card and 2 power supply card. AN-CH02 full configuration: 1 SNMP card, 12 function card and 2 power supply modules (1 redundant module)
AD-net AN-CH02 chassis support our complete fiber optical mux series,
AN-4E1-ETH, AN-8E1-ETH
Centralized SNMP rack mount solution allows network operator efficiently use expensive collocation place in racks, monitor network and deploy efficient fiber point-to-multipoint systems for access networks.
Why waste space in your 19′ rack by stacking standalone units on each other?
Choose AD-net SNMP platform to save space in your POP, and free GUI software with each order!
What’s different here with AN-CH01? While AN-CH01 supports more slots, giving you even more effiecient usage of space in your 19′ rack, AN-CH02, is most universal one – you can use it with AN-4E1-ETH, AN-8E1-ETH, that’s uniquie feature of AN-CH02
