Industrial Ethernet Switch(4TP+1F)

The 5 ports Industrial Ethernet Switch(5TP) are entry-level industrial Ethernet switches that provide an economical solution for your industrial Ethernet connection, support IEEE802.3/802.3u/802.3x. Dust proof and full close structure and the IP30 case with LED indicators make the plug - and - play switches easy to use and reliable. These switches have been designed for harsh industrial environments. It supports 4 TP ports 10/100Base-T(X), Full/Half duplex mode, and auto MDI/MDI-X connection.

  • IEEE802.3/ 802.3u/ 802.3x

  • Support auto negotiation speed, F/H duplex mode , and auto send data control

  • Plug-and-play, auto MDI/MDI-X connection

  • Store and Forward 100M

  • Switching process type

  • Broadcast storm protection

  • Network work state LED indicator

  • 12～36VDC  power input  Operating temperature ranges from -40 to 75°C

Interface

RJ45 Ports: 10/100BaseT(X) auto connection, Full /Half duplex or force work mode, and support MDI/MDI-X connection

Fiber Port: 100BaseFX ports (SC/ST/FC connector, optional)

Single-mode:20, 40,60, 80, 120Km,optional

Multi-mode: 2,5Km,optional

Wavelength: 850nm, 1310 nm, 1550nm

Technology

Standard：IEEE802.3, IEEE802.3x, IEEE802.3u

Forwarding and Filtrate Rate: 148810pps

Transmit type: Store and Forward switching process type

Support 1K MAC Address

Power

Input Voltage: 12VDC~36VDC,

Overload Current Protection

Connection: 3 bit terminal block

Mechanical

Dimensions (L×W×H): 103mm×78mm×32mm

Packaging: IP 30 Protection, Metal case

Environmental

Operating Temperature: -40 to 75°C

Storage Temperature: -45 to 85 °C

Ambient Relative Humidity: 10% to 95% (non-condensing)

Certification

FCC Class A, CE, RoHS

Approvals

E M I: FCC Part 15, CISPR (EN55022) class A

EMS: EN61000-4-2(ESD), Level 4

EN61000-4-3(RS), Level 3

EN61000-4-4(EFT), Level 4

EN61000-4-5(Surge), Level 4

EN61000-4-6(CS), Level 3

EN61000-4-8, Level 5

Shock: IEC 60068-2-27

Free Fall: IEC 60068-2-32

Vibration: IEC 60068-2-6

Warranty

5 Years

Description

The 5 ports Industrial Ethernet Switch(5TP) are entry-level industrial Ethernet switches that provide an economical solution for your industrial Ethernet connection, support IEEE802.3/802.3u/802.3x. Dust proof and full close structure and the IP30 case with LED indicators make the plug – and – play switches easy to use and reliable. These switches have been designed for

harsh industrial environments. It supports 4 TP ports 10/100Base-T(X), Full/Half duplex mode, and auto MDI/MDI-X connection.
